HBN 00-10 HTM64 (TB H2a) Markwik 21+ Panel Mounted Thermostatic Basin Mixer

A6735(AA) Markwik 21+ panel mounted thermostatic basin mixer, single sequential lever, demountable with fixed spout

Panel mounted thermostatic basin mixer with lever operation. Mainly used as a healthcare hospital mixer (TB H2a).Single lever sequential operation ensures both hot and cold water is drawn on each use. Long lever gives precise control. Insulated technology keeps the ‘hot’ side of the mixer at a safe surface temperature. Includes a built-in thermal cleansing feature. Variant available with removable spout for autoclave sterilisation, body demounts from panel for submergible disinfection and Bioguard outlet also helps protect against bacteria.

Conformsto HTM64 (2006), PRH 8941.0.6, HTM04-01, HBN 00.09.


  • Front access D-08 auditing&servicing
  • Conforms to HBN 04-01 Addendum 2014
  • Demount, submerge and disinfect
  • Bioguard against bacteria
  • Thermal disinfection feature
  • Available with fixed or removable spout

  • Chrome
    (AA)
Material: Chrome Plated Brass
Weight: 3.60Kg
HTM code: TB H2A


  • 1704021

View data sheet

Brassware

A6735 (TB H2A) Markwik 21+ panel mounted thermostatic basin mixer, single sequential lever, demountable with fixed spout

  1. Strada 70cm countertop basin one taphole

    Strada 70cm Countertop Washbasin One Taphole

    Strada 70cm countertop basin one taphole

  2. Markwik 21+ panel mounted thermostatic basin mixer, single sequential lever, demountable with removable spout

    Markwik 21+ Panel Mounted Thermostatic Basin Mixer

    Markwik 21+ panel mounted thermostatic basin mixer, single sequential lever, demountable with removable spout

  3. Markwik 21+ panel mounted thermostatic basin mixer, time flow sensor, demountable with removable spout

    Markwik 21+ Panel Mounted Thermostatic Basin Mixer

    Markwik 21+ panel mounted thermostatic basin mixer, time flow sensor, demountable with removable spout

  4. Markwik 21+ 2 hole thermostatic basin mixer, single sequential lever, demountable

    Markwik 21+ 2 Hole Thermostatic Basin Mixer

    Markwik 21+ 2 hole thermostatic basin mixer, single sequential lever, demountable

  5. Markwik 21+ 1 hole thermostatic basin mixer, single sequential lever, demountable with copper tails

    Markwik 21+ 1 Hole Thermostatic Basin Mixer

    Markwik 21+ 1 hole thermostatic basin mixer, single sequential lever, demountable with copper tails

Ancillary

A6899 Markwik 21+ purging kit for panel mounted thermostatic mixers

Variants

Special notes

Single lever for on/off operation and temperature control. Especially suited to medium and large hospital pattern integral back outlet basins and washing associated with clinical or nursing procedures. Fitted with an Armitage Bioguard outlet which reduces the opportunity for biofilm attachment and is lined with anti-microbial copper. Unique built-in thermal disinfection cleansing feature. Body demounts for submergible disinfection. Suitable for high and low pressure systems. Flow rate regulated to maximum of 10 Litres per minute. A separate purging kit is available to facilitate initial installation flushing and water sampling.

Variants
