Doc M Wall Mounted - Individual Items

S3078(01) Contour 21 rimless wall mounted WC pan with horizontal outlet, 75cm projection

Individual items for LH Doc M wall mounted pack, choosing the optional washbasin from individual items gives items for RH Doc M wall mounted pack. All Doc m packs are specifically designed to latest recommendations which call for the tap to be positioned more conveniently on the side of the basin closest to the seated user. For right hand corner arrangement substitute washbasin S247401 for S247301.

For the complete pack that these items relate to see S6972 (left hand) and S6973 (right hand) pack codes.

  • For individual items see "illustrated" tab

  • White
Material: Vitreous China
Weight: 32.11Kg

View data sheet

WC Pan

S3078(01) Contour 21 rimless wall mounted WC pan with horizontal outlet, 75cm projection


S2474(01) Contour 21 37cm handrinse washbasin right hand taphole no overflow or chainstay hole, bottom outlet

Washbasin Wall Fixings

S9110(67) Hangers concealed, Steel

Grab Rails

S6484(AA) Contour 21 Contemporary grab rail 60cm long (x4)

Grab Rails

S6486(AA) Contour 21 Contemporary grab rail 45cm long

Grab Rails

S6362(AA) Contemporary 21 hinged support rail, 80cm Doc M Compliant


N1381(AA) Concept toilet roll holder


E0079(AA) Trap 1¼" Contemporary metal bottle, 75mm seal


S8803(AA) Waste 1¼" Click plug waste, 80mm slotted tail


A6790(AA) Contour 21+ Outline 1 hole thermostatic basin mixer, single sequential lever with flexible tails


S3636(67) Conceala 2 cistern delay fill 4.5/3 or 4/2.6 litre dual flush valve bottom supply and internal overflow, alternative height plastic flushbends, no flushplate

WC Seat

S4066(01) Contour 21 seat no cover, top fixing hinges and retaining buffers

WC Actuator

S4397(AA) Contemporary flush plate dual flush, Armitage Shanks logo for Conceala 2 cisterns

WC Support Bracket

S9139(67) Support bracket for wall mounted WC raised height with bolts

WC Back Support

S6637(AC) Multi-System back support, white, complete with cushion

WC Extended Flushpipe

S4302(67) Contour 21 flushpipe constructed, necessary for installation

WC Outlet Connector

S4303(67) Contour 21 outlet extension connector for 70/75cm WC pan outlet

Special notes

For LRV and RAL numbers see Doc M introduction. For right hand corner arrangement substitute S247401 for S247301. 600mm grab rail S6484 x 4 for room set 450mm grab rail S6486 is for back of door
