Contour 21+ Outline 1 Hole Thermostatic Basin Mixer

A6790(AA) Contour 21+ Outline 1 hole thermostatic basin mixer, single sequential lever with flexible tails

Deck mounted thermostatic basin mixer with lever operation for use on one taphole basins.  Single lever sequential operation ensures both hot and cold water is drawn on each use.  Pin single lever handle has an improved aesthetic than the standard lever handle.  Fitted with flexible tails with 15mm compression connections.  Factory fitted with a 3.8 litre per minute laminar flow regulator with anti-vandal housing.  2 litre per minute eco spray outlet also supplied loose in the box.


  • Commercial and DocM use
  • Integral thermostat
  • Eliminates the need for pre-mixed water
  • Standard pillar taphole
  • Flexible tail outlets

  • Chrome
    (AA)
  • Silk Black
    (XG)
Material: Chrome Plated Brass
Weight: 2.10Kg
Flow rate: 3.9 Litres per minute @ 3 bar pressure


Data Sheet Spares Where to Buy

Brassware

A6790(AA) Contour 21+ Outline 1 hole thermostatic basin mixer, single sequential lever with flexible tails

  1. Contour 21 toilet seat only, top fixing hinges and retaining buffers

    Contour 21 Seat No Cover, Top Fixing Hinges & Retaining Buffers

    Contour 21 toilet seat only, top fixing hinges and retaining buffers

  2. Contour 21 toilet seat and cover, top fixing hinges

    Contour 21 Seat & Cover, Top Fixing Hinges

    Contour 21 toilet seat and cover, top fixing hinges

  3. Contour 21+ back-to-wall rimless toilet bowl with raised horizontal outlet and anti-microbial glaze

    Contour 21+ Back-to-Wall Rimless Toilet Bowl

    Contour 21+ back-to-wall rimless toilet bowl with raised horizontal outlet and anti-microbial glaze

  4. Contour 21+ 1 hole thermostatic basin mixer, single sequential lever with copper tails

    Contour 21+ 1 Hole Thermostatic Basin Mixer with Copper Tails

    Contour 21+ 1 hole thermostatic basin mixer, single sequential lever with copper tails

  5. Contour 21+ Outline 1 hole thermostatic basin mixer, single sequential lever with flexible tails

    Contour 21+ Outline 1 Hole Thermostatic Basin Mixer with Flexible Tails

    Contour 21+ Outline 1 hole thermostatic basin mixer, single sequential lever with flexible tails

  6. Contour 21+ 50cm back outlet washbasin, no tapholes, anti-splash and anti-microbial glaze

    Contour 21+ 50cm Back Outlet Washbasin

    Contour 21+ 50cm back outlet washbasin, no tapholes, anti-splash and anti-microbial glaze

  7. Contour 21+ 60cm back outlet washbasin, no tapholes, anti-splash and anti-microbial glaze

    Contour 21+ 60cm Back Outlet Washbasin

    Contour 21+ 60cm back outlet washbasin, no tapholes, anti-splash and anti-microbial glaze

  8. Contour 21+ 50cm back outlet washbasin, one right hand taphole and anti-microbial glaze

    Contour 21+ 50cm Back Outlet Washbasin

    Contour 21+ 50cm back outlet washbasin, one right hand taphole and anti-microbial glaze

  9. Contour 21+ 40cm back outlet washbasin, one right hand taphole and anti-microbial glaze

    Contour 21+ 40cm Back Outlet Washbasin

    Contour 21+ 40cm back outlet washbasin, one right hand taphole and anti-microbial glaze

  10. Contour 21+ 70cm projection back-to-wall rimless toilet bowl with horizontal outlet and anti-microbial glaze

    Contour 21+ 70cm Projection Back-to-Wall Rimless Toilet Bowl

    Contour 21+ 70cm projection back-to-wall rimless toilet bowl with horizontal outlet and anti-microbial glaze

  11. Contour 21+ 75cm projection back-to-wall rimless toilet bowl with horizontal outlet and anti-microbial glaze

    Contour 21+ 75cm Projection Back to Wall Rimless Toilet Bowl

    Contour 21+ 75cm projection back-to-wall rimless toilet bowl with horizontal outlet and anti-microbial glaze

  12. Contour 21+ raised height back-to-wall rimless toilet bowl with raised horizontal outlet and anti-microbial glaze

    Contour 21+ Raised Height Back-to-Wall Rimless Toilet Bowl

    Contour 21+ raised height back-to-wall rimless toilet bowl with raised horizontal outlet and anti-microbial glaze

  13. Contour 21+ wall hung rimless toilet bowl with horizontal outlet and anti-microbial glaze

    Contour 21+ Wall Hung Rimless Toilet Bowl

    Contour 21+ wall hung rimless toilet bowl with horizontal outlet and anti-microbial glaze

  14. Contour 21+ 1 hole thermostatic basin mixer, single sequential lever with flexible tails

    Contour 21+ 1 Hole Thermostatic Basin Mixer with Flexible Tails

    Contour 21+ 1 hole thermostatic basin mixer, single sequential lever with flexible tails

Special notes

Single sequential lever for on/off operation and temperature control. Supplied with service valves which include isolators, strainers, check valves, flow regulators and 15mm compression connections. Temperature factory set to 40±1°C. Product will work on low pressure providing the flow regulator is removed and replaced using a flow guide (A960191NU). Factory fitted 3.8 litre per minute flow regulator in an anti-vandal housing. 1.9 litres per minute eco spray outlet also supplied. Both require 1 bar minimum pressure. Clamping ring with three fixing screws for secure fix to the basin which will not come loose if installed correctly.
