Portman 21 60cm Washbasin

S2257(01) Portman 21 washbasin 60cm, 2 tapholes with overflow and chainstay hole

Modern design washbasin in vitreous china in 3 sizes, 60cm, 50cm and 40cm.


  • Commercial and domestic use
  • Anti vandal applications
  • Three sizes available
  • With or without overflow
  • 3 taphole options for 60cm basin
  • Option for wall or panel fixing set

  • White
    (01)
Material: Vitreous China
Weight: 16.79Kg
Width: 60mm
Depth: 48mm


Data Sheet Spares Where to Buy

Washbasin

S2257(01) Portman 21 washbasin 60cm, 2 tapholes with overflow and chainstay hole

Waste

S8800(AA) Waste 1¼" plastic waste with bead chain and plug, 80mm slotted tail, bolt stay

Trap

S8920(67) Trap 1¼" plastic resealing bottle, 75mm seal, multi-purpose outlet

Washbasin Wall Fixings

E0157(67) Wall fixing set

Washbasin Wall Fixings

E0062(67) Basin fixing set for IPS panels or block walls

Brassware

B8267(AA) Avon 21 inclined non-concussive washbasin pillar taps (pair) with dual hot and cold indices per tap, self closing push button, water saving anti-vandal spout regulated to 3.7 litres per minute maximum

Thermostatic Valve

A5900(AA) TMV thermostatic mixing valve, 15mm

Variants

Special notes

S9137 Bracket for 60cm basin. Recommended fixing heights (floor to front rim); Nursery use 600mm Infant use 700mm Junior use 750mm Senior/adult use 780-800mm. Washbasin wall mounted using E015767 wall fixing set or panel mounted using E006267 fixing set

Variants
