Washbasin wall mounted using E0157 wall fixing set with semi-pedestal fixed to wall with brackets supplied, or full pedestal mounted using 2 screws through the back of the basin (not supplied). When fitted with furniture washbasin must be secured to wall with E0157 wall fixing set

Designer

Robin Levien, RDI

Suitable for use wall or pedestal fixing and also can be used with design linked Cube furniture basin units.

  • Domestic and commercial use
  • One and two taphole options
  • Part of the extensive Concept suite
  • Furniture base unit to match

Illustrated

  1. E8031(01)

    Concept Cube 40cm handrinse washbasin, 1 taphole with overflow

  2. E7840(01)

    Concept small semi-pedestal

  3. E0157(67)

    Wall fixing set

  4. B8062(AA)

    Active single lever one hole basin mixer with pop-up waste.

  5. S8950(67)

    Trap 1¼" plastic P for use with cloakroom pedestal

Configuration options

  1. E7838(01)

    Concept handrinse pedestal

  2. E6443(SO)

    Concept 300 x 300mm full pedestal washbasin unit with 1 door (Available in Dark Walnut (SX), Gloss White (WG), Gloss Grey (KR), Elm (KS))

Material

Fine Fireclay

Weights

  1. E8031 10.08 KG
  2. E7840 5.58 KG
  3. E0157 0.16 KG
  4. B8062 2.42 KG
  5. S8950 1.00 KG

Capacity

2

Finish key

  1. enlarge (01) White
  2. enlarge (67) Neutral / No Finish
  3. enlarge (AA) Chromium plated
  4. enlarge (KR) Gloss Grey
  5. enlarge (KS) Elm
  6. enlarge (SO) American Oak
  7. enlarge (SX) Dark Walnut
  8. enlarge (WG) Gloss White

Standards

Washbasin to BS EN 14688 & BS EN 31

Alternate options

  1. Default configuration

    1. E8032(01)

      Concept Cube 40cm handrinse washbasin, 2 tapholes with overflow and chainstay hole

    2. E7838(01)

      Concept handrinse pedestal

    3. B9925(AA)

      Concept washbasin pillar taps

    4. S8800(AA)

      Waste 1¼" plastic waste with bead chain and plug, 80mm slotted tail, bolt stay

    5. S8910(67)

      Trap 1¼" plastic bottle, 75mm seal, multi-purpose outlet

    Configuration options

    1. E7840(01)

      Concept small semi-pedestal

    2. E6443(SO)

      Concept 300 x 300mm full pedestal washbasin unit with 1 door (Available in Dark Walnut (SX), Gloss White (WG), Gloss Grey (KR), Elm (KS))

    3. E0157(67)

      Wall fixing set

    4. B7884(AA)

      Ceraplan basin pillar taps with lever handles

    5. B5105(AA)

      Cone basin pillar taps with lever handles

View full suite
