(HBN 00-10) Denholm (New) Stainless Steel 51cm Washbasin With Shroud

S1271(MY) Denholm (New) 51cm stainless steel washbasin and full shroud complete with 2 corner tapholes, combined chainstay and overflow waste

New style 51cm x 42cm vandal resistant stainless steel washbasin with shroud to conceal plumbing fittings.

Stainless steel
Anti-vandal
Duct or surface fixing

Finishes

Stainless Steel finish
(MY)

Material:	Stainless Steel
Weight:	11.00Kg
Width:	51mm
Depth:	42mm

Standards: Steel sheet conforms to BS EN 10088:Part2:2005 Material 1.4301 (304) - 0.9mm. NHS specification HBN 00-10. EN 14688.

Data Sheet Spares Where to Buy

Washbasin

S1271(MY) Denholm (New) 51cm stainless steel washbasin and full shroud complete with 2 corner tapholes, combined chainstay and overflow waste

Brassware

B8267(AA) Avon 21 inclined non-concussive washbasin pillar taps (pair) with dual hot and cold indices per tap, self closing push button, water saving anti-vandal spout regulated to 3.7 litres per minute maximum

Waste

S8733(AA) Waste 1¼" brass anti theft swivel plug waste, 80mm slotted tail

Trap

S8920(67) Trap 1¼" plastic resealing bottle, 75mm seal, multi-purpose outlet

Sectors & Solutions

Education

Sports and Leisure

Anti-Vandal

Special notes

Earthing tag and brackets and full shroud included. Consideration should be given to safe hot water delivery and the use of an appropriate temperature reduction device see A5900AA or Part G for guidance. Stainless steel screw to wall brackets and bolts included.

Material:	Chrome Plated Brass
Weight:	2.25 Kg
Flow rate:	3.7 Litres per minute @ 3 bar pressure

Material:	Plastic
Weight:	2.00 Kg
HTM code:	TRR1/P

(HBN 00-10) Denholm (New) Stainless Steel 51cm Washbasin With Shroud

51cm Washbasin

Pillar Taps

1¼" Anti Theft Swivel Plug Waste

Trap 1¼" Plastic Bottle Resealing

Sectors & Solutions

Special notes

Resources to download
